What's new in version V2?

The V2 board was released on May 7th, 2014 as the successor to the very popular V1 board with the following improvements and differences:

Auto calibration

Version 2 will no longer be dependent on specialized external test equipment and software tools for initial calibration and tuning of the LDRs. All of that is now self-contained in the board itself. In the event one or more LDRs age differently and drift out of calibration, the LDR3x.V2 can adjust each LDR's attenuation table to bring the unit back into precise calibration. This also mitigates dependence on having to use matched sets of LDRs in each build. Also, owners are no longer dependent on us for storing and maintaining their calibration data should updates be needed in the future.

Replaceable LDR modules

LDRs are similar to tubes insofar as they are nonlinear analog devices. They have an internal LED light source, they don't behave exactly the same from one to the next even if the same make/model, their performance characteristics can change over time, some fail early on, and they eventually age and die (although 50,000 hours is a long life). Wouldn't it be nice to just yank a bad one out, and stick in a nice new one for around $20? Done!

Increased precision

Whereas the V1 used 8 bit digital pots, the V2 board employs both 12 bit DACs and ADCs. This gives the LDR3x.V2 16 times greater precision in adjusting the resistance values of the LDRs. This means more precise channel matching over the full attenuation range and that translates directly into improved stereo imaging and sound stage.

Quieter power supply

Version 2 replaces a linear voltage regulator with a precision low noise switching power supply module with superior ripple rejection. The result is a darker background between the notes and improved articulation and expression of sound. What does this mean? It now sounds even better!

Software updates via USB

Version 2 uses an on-chip USB bootloader which allows software updates to be handled via a USB connection to a PC. Thus, software updates can downloaded from our website out and owners can upload the latest software into their V2 board from their laptop/desktop PC. Eventually this will also be doable from a Mac as well.

Fewer Control Interface Options

The downside of all these cool improvements is fewer DIY control interface options although control via both IR remote and manual encoder remain unchanged. Control via discrete channel select inputs and analog pot are no longer available.

The LDR3x.V2 - What Is It?

The LDR3x.V2 is an a DIY passive preamp controller designed around light dependent resistors (LDRs) that allows the DIY'er to build a passive or active preamp with exceptional audio performance that can be controlled with a remote.

Digitally controlled, analog audio preamp controller in the form of a populated 2.5 inches wide by 4.7 inches long printed circuit board
Controllable via the Apple IR Remote (not supplied) (in the future will also be controllable via smartphones with IR capability)
Allows the DIY audio enthusiast to build their own exceptionally transparent and articulate balanced or unbalanced audio preamplifer
Rivals the performance of even the best high end preamp costing 10-100 times more than the LDR3x.V2
By itself is an unrivaled passive preamp/controller but can also be incorporated into any DIY active preamp design
Utilizes light superior sounding dependent resistors (“LDR”) in lieu of conventional potentiometers or stepped resistive attenuators for volume control
Precision control of the LDRs and all other functionality of the LDR3x.V2 is done via a software driven on-board digital microcontroller

What Does It Do?

The LDR3x.V2 is a fully functional LDR based passive preamp volume controller
Attenuates from approximately -60 to 0 dB via a custom 70 step attenuation curve
Continually auto-calibrates its LDRs while turned off (and connected to power)
Includes muting with smooth ramp down and ramp up
Accepts one (1) single ended unbalanced stereo input (single V2 board)
Accepts one (1) balanced stereo input (requires dual V2 boards configured as master/slave)
Can switch between 3 inputs (unbalanced or balanced) when mated with our IO3 relay board (or equivalent)
Fully controllable via infrared remote
Fully controllable via an encoder with integral switch (see our Encode Module)
Status output than can drive a status LED
Can be interfaced with the 7 segment DM1 Display Module to display volume step & unit status
Provides traditional left/right channel balance for fine tuning
Optical isolation between audio and power/control signals - pure resistive pass-through attenuation
Provides a 12 VDC trigger out to turn other audio system components on/off
Runs off of most any 12 VDC power supply

Unbalanced RCA or Balanced XLR Audio

Unbalanced

A single LDR3x.V2 board (paired with an optional input relay module) accommodates up to 3 unbalanced (single-ended) audio inputs.

Unbalanced

Two LDR3x.V2 boards (each paired with an optional input relay module) can be configured to accommodates up to 3 balanced audio inputs. One board is designated as the Master (the right channel) and the other is designated as the Slave. This is done via the setting of jumpers on the board together with a 3 wire control cable between the 2 boards.

What's Included?

Tortuga Audio 2.5 by 4.7 inch printed circuit LDR3x.V2 Board populated with components
Vishay TSOP31138 38kHz high performance IR Receiver which can be inserted/soldered into the V2, a DM1 module or otherwise located external to the board

What else is Required & What Options Are Available?

To implement the most basic LDR3x system, in addition to the LR3x.V2 board itself, the DIY'er will need to supply the following additional items:

Apple Remote and/or Encoder Module - (both sold by Tortuga Audio)
12 V DC power supply (0.5 amp or higher) - (sold by Tortuga Audio)
RCA jacks and wiring for connecting the audio input/ouput to the V2 board - (sold by Tortuga Audio)
Typically you'll also want an enclosure to house the preamp
